SiC Lateral High Voltage Bi

Modern power electronics demand high efficiency and compactness, particularly for electric vehicles and renewable energy systems. While silicon carbide (SiC) allows for higher voltages and switching frequencies than traditional silicon, standard MOSFETs cannot block voltage in both directions when turned off. Current industry workarounds involve placing two separate SiC chips side-by-side, which increases chip size and reduces manufacturing yields.
A new lateral high-voltage bi-directional FET addresses these limitations by integrating bidirectional functionality directly into the unit-cell structure. By incorporating a Schottky diode within each cell, the device improves conductivity and enables voltage blocking in both directions within a single, compact lateral architecture. This design facilitates easier integration into complex integrated circuits. Currently at TRL 4 with a patent pending, the technology is available for licensing to support the development of miniaturized power electronic systems, such as matrix converters and smart grid switches.

* Silicon carbide (SiC) is used as the material for a lateral high-voltage bi-directional field-effect transistor (FET).
* The device conducts current and blocks voltage in both forward and reverse directions.
* The technology utilizes a unit-cell structure where bidirectional functionality is integrated at the cell level.
* Each unit cell incorporates a Schottky diode.
* The device features a lateral architecture.
* Targeted applications include current-source inverters and matrix converters.
* This technology is currently at Technology Readiness Level (TRL) 4.
* The intellectual property status is patent pending.
* The technology is available for licensing.
* Other potential applications include bidirectional electric vehicle chargers, renewable energy power conversion, and smart grid solid-state switches.
